HPE Aruba Networking Aruba Instant On 1960 24G 20p Class4 4p Class6 PoE 2XGT 2SFP+ 370W. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 16000 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE…. Power over Ethernet (PoE). Rack mounting, Form factor: 1U

HPE Networking Instant On Switch 1960 series, consist of advanced, smart-managed, fixed configuration Gigabit stackable switches designed for small and growing businesses that are easy to deploy and affordable. These switches are designed to scale as business grows, making adding more employees, devices and applications simple. Instant On 1960 switches are made to handle today’s bandwidth-heavy applications like voice and video conferencing, enabling consistent connectivity to improve user experience and application performance. These switches come with flexible management option: local web GUI or Instant On mobile app and cloud-based web portal.

Specification
Product Description HPE Networking Instant On 1960 24G 2XGT 2SFP+ Switch – switch – 24 ports – Managed – rack-mountable
Device TypeSwitch – 24 ports – Managed
Enclosure TypeRack-mountable 1U
SubtypeGigabit Ethernet
Ports24 x 10/100/1000 + 2 x 10 Gigabit SFP+ + 2 x 100/1000/10GBase-T
PerformanceThroughput: 95 Mpps ¦ Switching capacity: 128 Gbps ¦ Latency (100 Mbps): 4.4 µs ¦ Latency (1 Gbps): 2.2 µs ¦ Latency (10 Gbps): 1.1 µs
CapacityMAC address entries: 16000 ¦ IPv4 routes (static): 32 ¦ IPv6 routes (static): 32
MAC Address Table Size16000 entries
Jumbo Frame Support9216 bytes
Routing ProtocolStatic IP routing
Remote Management ProtocolRADIUS, SNMP 1, SNMP 2c, SNMP 3, HTTP, HTTPS
FeaturesFanless, EEE, ARP support, auto-uplink (auto MDI/MDI-X), DHCP support, TPM, VLAN support, auto voice VLAN, LLDP-MED, LACP, STP support, BPDU Filter, flow control, IPv6 support, auto-negotiation, ACL support, CoS, port mirroring, half duplex mode, full duplex mode
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
PowerAC 100-240 V (50/60 Hz)
Dimensions (WxDxH)44.25 cm x 35.05 cm x 4.395 cm
Weight3.9 kg
